MIL-DTL-10058J
TABLE II. First article inspection (continued).
Moisture content (7549246-1)
Flash composition
8865588
Note d.
3.3.1
4.5.1 / 4.7.1
Whistle composition
7549235
Note d.
3.3.2
4.5.1 / 4.7.1
Flash composition formulation
12972326
Note e.
3.3.3
4.5.2 / 4.7.2
Flash composition granulation
12972326
Note e.
3.3.4
4.5.2 / 4.7.2
Moisture content (7549246-2)
13020526
Flash composition
Note d.
3.3.1
4.5.1 / 4.7.1
7549235
Whistle composition
Note d.
3.3.2
4.5.1 / 4.7.1
13019989
Flash composition formulation
Note e.
3.3.3
4.5.2 / 4.7.2
13019989
Flash composition granulation
Note e.
3.3.4
4.5.2 / 4.7.2
Simulator (complete assembly)
7549246
Examination for defects
50
3.2.11
4.3.2.12
Jumble
10
3.4
4.7.3
Functioning ambient @ 65°F to 75°F
20 (Note b)
3.5
4.5.3
Functioning cold @ -70°F to -60°F
10 (Note c)
3.5
4.5.3
Notes:
a. Test and acceptance in accordance with first article requirements of MIL-I-12597.
b. Ten assemblies functioned in static (4.7.4.1.1) and non- static phase (4.7.4.1.2).
c. Ten assemblies functioned in the non- static phase (4.7.4.1.2).
d. Test and acceptance in accordance with first article requirements from paragraphs 4.5.1 and 4.7.1.
e. Test and acceptance in accordance with first article requirements from paragraphs 4.5.2 and 4.7.2.
4.3 Conformance inspection.
4.3.1 Inspection lot formation. Inspection lot is defined as a homogeneous collection of
units of product from which a representative sample is drawn or which is inspected 100 percent
to determine conformance of applicable requirements. Units of product selected for inspection
shall represent only the inspection lot from which drawn and shall not be construed to represent
any prior or subsequent quantities presented for inspection. Homogeneity shall be considered to
exist provided the inspection lot has been produced by one manufacturer, in one unchanged
process, using the same materials and methods, in accordance with the same drawings, same
drawing revision, same specifications and same specification revisions and complies with
provisions for submission of product as a specified in MIL-STD-1916, paragraph "Acceptance
by tables."
4.3.1.1 Lot numbering. All material submitted for inspection in accordance with this
specification shall comply with the homogeneity criteria specified herein, regardless of the type
of inspection procedure which is being applied to determine conformance with requirements. In
addition, inspection lots of loaded simulators shall contain:
a. Parts from one lot interfix from one manufacturer.
b. Safety fuze from not more than one lot interfix number from one
manufacturer.
c. Each ingredient of the flash and whistle composition of one lot interfix
number from not more than one manufacturer.
10
