MIL-DTL-10057J
TABLE II. First article inspection
Drawing
No. of
Requirement
Inspection Method/
Examination or Test
number
samples
Paragraph
Reference
Disc
9252461
Examination for defects
25
3.2.1
4.3.2.1
Upper disc
9256462
Examination for defects
25
3.2.2
4.3.2.2
Inner tube
9256464
Examination for defects
25
3.2.3
4.3.2.3
Outer tube
9256465
Examination for defects
25
3.2.4
4.3.2.4
Disc and fuze cord assembly
9256463
Examination for defects
25
3.2.5
4.3.2.5
Priming paste support
12912921
Examination for defects
25
3.2.6
4.3.2.6
Spacer tube
13013011
Examination for defects
25
3.2.7
4.3.2.7
Cover and body assembly
9256466
Examination for defects
25
3.2.8
4.3.2.8
Cover and body loading assembly (BP-Al)
9257901
Examination for defects
25
3.2.9
4.3.2.9
Cover and body loading assembly (Al-KP)
13019988
Examination for defects
25
3.2.10
4.3.2.10
M3A1 igniter assembly
8833721
Examination for defects
Note a.
3.2.12
Note a.
Safety fuze cord
9345134
Examination for defects
25
3.2.13
4.3.2.5
Moisture content (9256467-1)
Flash composition
9257901
Note d.
3.3.1
4.7.1
Flash composition formulation
12972326
Note e.
3.3.2
4.7.2
Flash composition granulation
12972326
Note e.
3.3.3
4.7.2
Moisture content (9256467-2)
Flash composition
13019988
Note d.
3.3.1
4.7.1
Flash composition formulation
13019989
Note e.
3.3.2
4.7.2
Flash composition granulation
13019989
Note e.
3.3.3
4.7.2
Hand grenade simulator M116A1assembly
9256467
Examination for defects
50
3.2.11
4.3.2.11
Jumble
10
3.4
4.7.3
Functioning ambient @ 65°F to 75°F
20 (Note b)
3.5
4.5.3
Functioning cold @ -70°F to -60°F
10 (Note c)
3.5
4.5.3
8
