MIL-DTL-20517J (AR)
PARAGRAPH
TITLE
DRAWING NUMBER
8848483
4.3.2.15
Charge Case - Continued
NEXT HIGHER
ASSEMBLY
8848485
No. of
Requirement
Paragraph Reference/
Category
Examination or Test
Sample
VL or 100%
Paragraph
Inspection Method
Units
Minor
201
Inside diameter, max.
II
3.2.15
Gage
202
Thickness through bottom, min.
II
3.2.15
Gage
203
Evidence of poor workmanship
II
Visual
3.7
Notes:
PARAGRAPH
TITLE
DRAWING NUMBER
8848485
NEXT HIGHER
Charge Case Loading Assembly Prior to Crimping Closing Disc
4.3.2.16
ASSEMBLY
8848486
No. of
Requirement
Paragraph Reference/
Category
Examination or Test
Sample
VL or 100%
Paragraph
Inspection Method
Units
Critical
None defined
Major
101
Any component missing
IV
Visual
3.2.16
102
Fuze assembly loose or not fully seated
IV
3.2.16
Manual
103
Petman Cement missing from fuze thread (not 360 degrees)
3.2.16
Visual
note (a)
Minor
II
Visual
201
Evidence of poor workmanship
3.7
Notes: Note 1: For every hour of production, randomly select a sample of 15 units for inspection. Any evidence of noncompliance with the
applicable requirement shall cause that hour's production to be 100% inspected and defective units shall be removed from the lot.
21
