MIL-DTL-20517J (AR)
PARAGRAPH
TITLE
DRAWING NUMBER
12977377
4.3.2.12
Fuze Assembly - Continued
NEXT HIGHER ASSEMBLY
8848485
No. of
Requirement
Paragraph Reference/
Category
Examination or Test
Sample
VL or 100%
Paragraph
Inspection Method
Units
but not below 300 mg
100%
Gage
3.2.12.2
Minor
Evidence of poor workmanship
201
II
3.7
Visual
Note: Note 1: Gage shall be automated in accordance with MIL-A-70625
PARAGRAPH
TITLE
DRAWING NUMBER
12977377
NEXT HIGHER ASSEMBLY
4.3.2.13
Fuze Assembly Complete
8848485
No. of
Requirement
Paragraph Reference/
Category
Examination or Test
Sample
VL or 100%
Paragraph
Inspection Method
Units
Critical
1
Fuze assembly empty or improperly loaded (voids, missing
increments, inconsistent densities)
100% & VII
4.5.7
3.2.13
2
Cracks on fuze assembly housing
100% & VII
3.2.12.2
4.5.7
Major
101
No indication of cone at end of fuze assembly
100%
4.5.7
3.2.13
Minor
201
Evidence of poor workmanship
II
3.7
4.5.7
Notes:
19
