MIL-DTL-10058J
DRAWING NUMBER
12972326 or 13019989
Charge loading assembly, prior to
4.3.2.9
NEXT HIGHER
sealing cup assembly.
ASSEMBLY
7549246
CONFORMANCE
REQUIREMENT
EXAMINATION OR TEST
INSPECTION
CLASSIFICATION
CRITERIA
PARAGRAPH
METHOD
Critical
None defined
Major
Weight of charge
101
Note a
3.2.8
Balance
Minor
Evidence of poor workmanship
201
VL-II
3.7
Visual
NOTES:
a. A sample of fifty (50) charge loading assemblies, prior to sealing the cup assembly shall be selected from each four (4) hours
of production and subjected to a weight of charge verification as follows:
Using a tared whistle and cover assembly (dwg. 7549235), the weight difference due to the addition of the flash composition
is determined. If the weight of the charge fails to meet the applicable requirements, those assemblies loaded since the last
acceptable verification test shall be classed defective and removed from the lot. (non-destructive test).
Alternate Method: Empty the contents of the charge loading assembly (dwg. 8865588) into a tared pan and determine the
weight of the flash composition.
