MIL-DTL-10058J
each lot for test. All assemblies shall be functioned in the non-static phase. The lot shall be
rejected if, during the test, any of the following is exhibited.
a. One or more critical defects.
b. Four (4) or more assemblies having major defects listed in Table V.
4.5.3.2.2 Successive lot test. After three consecutive lots have complied with the criteria
of 4.5.3.2.1, 50 simulators shall be selected from each lot for this test. All assemblies shall be
functioned in the non-static phase. The lot shall be rejected if, during the test, any of the
following are exhibited.
a. One or more critical defects.
b. Three or more assemblies having major defects listed in Table V.
If the lot is rejected, the next lot produced will proceed as if it is the first lot being produced, and
shall follow the requirements of 4.5.3.1.1 and 4.5.3.2.1 until 3 consecutive lots are accepted.
TABLE VI. Destructive test.
Reduced Sampling Plan
Initial
(After 3 consecutive complying lots)
Temp.
Number
Reject if a critical defect or any
Number Reject if a critical defect or
of Tests
of the following occur
of Tests any of the following occur
Three (3) or more major
defects
Ambient
125
Six (6) or more major defects
50
Three (3) or more major
defects
Four (4) or more major defects
Cold
80
50
Note: If a lot fails or withheld from
submission during the reduced
sampling plan, the next lot will go
back to initial testing until another 3
consecutive lots have complied with
the acceptance criteria
4.6 Fuze length and delay.
4.6.1 Determination of critical fuze length. For each spool of fuze cord, a sample of 30
pieces of fuze nominally three (3) inches shall be cut. Fuze cords shall be cut (10 each) from the
beginning, middle and end of the spool with respect to the lot size. Determine the average burn
28
