MIL-DTL-10058J
4.5 Testing.
4.5.1 Moisture content. Major defect.
TABLE III. Major defects for moisture content.
Material
Drawing
Inspection Method Paragraph
Whistle
7549227
4.7.1.1
Flash composition or ingredients
8865588
4.7.1.2
or
13020526
4.5.1.1 Material samples moisture content. For verification, one sample of each material
as representative of eight (8) hours of production of simulators shall be selected and subject to
test. Composite samples shall not be used. If the moisture content of the sample exceeds the
requirement, that quantity or sub-lot of material represented by the sample shall not be used in
production. If the quantity of material or sub-lot with excessive moisture has been used in
loading and packing, the remaining unloaded and unpacked material shall not be used in
production, and the loaded and packed simulators shall be rejected.
4.5.1.2 Simulator ingredients moisture content. A sample of sufficient size (see paragraph
4.7.1) from each lot of each ingredient at the time of inserting the ingredient to the simulator for
determination of moisture content shall be selected. Controls shall be provided so that the
moisture content is maintained under constant temperature and humidity by a graphic recorder
up to and at the time of sealing and blending the charge in the simulators. If the sample fails to
meet the requirements, or if the simulators have been loaded with ingredients containing
excessive moisture, the remainder of the ingredient lot shall not be used in further production,
and the lot of loaded simulators shall be rejected.
4.5.2 Determination of granulation and composition of flash powder Major defect.
TABLE IV. Major defects for granulation and composition of flash powder.
Inspection Method
Material
Drawing
Paragraph
Granulation
12972326 or
4.7.2.1
13019989
Composition
12972326 or
4.7.2.2
13019989
4.5.2.1 Flash composition samples. Adequate controls to insure that the flash composition
complies with the requirements shall be provided. Test for verification at least, one sample of
the composition of sufficient size (see paragraph 4.7.2) as representative of each eight (8) hours
production of simulators shall be provided. A composite sample shall not be used. If the sample
fails to meet the requirements for granulation or composition, or if the simulator has been loaded
and packed with non-conforming composition, the remaining unloaded composition shall not be
used in production and the lot of loaded simulators shall be rejected.
26
