MIL-DTL-20517J (AR)
TABLE I. Requirements/Verification Cross Reference Matrix - Continued
METHODS OF VERIFICATION
CLASSES OF VERIFICATION
1 - Analysis
A - First Article
2 - Demonstration
3 - Examination
B Conformance
4 - Test
Section 3
Verification
Description
Section 4
Verification Methods
Requirements
Class
N/A
1
2
3
4
A
B
3.3
4.3.2.17; 4.4.5;
Fragmentation
X
X
4.5.4
3.4
4.3.2.21; 4.4.6;
Dynamic functioning
X
X
X
4.5.5
3.4.1
4.3.2.21; 4.4.6;
Case failure
X
X
X
4.5.5
3.4.2
4.3.2.21; 4.4.6;
Burst
X
X
X
4.5.5
3.4.3
4.3.2.21; 4.4.6;
Burst time
X
X
X
X
X
4.5.5
3.4.4
4.3.2.21; 4.4.6;
Expelling time
X
X
X
X
4.5.5
3.4.5
Horizontal distance and
4.3.2.21; 4.4.6;
X
X
X
X
altitude
4.5.5
3.4.6
Primer functioning
4.3.2.21; 4.4.6
X
X
X
3.5
Primer deterioration
4.4.7
X
X
X
3.6
4.3.2.21; 4.4.8;
Air leakage test
X
X
X
4.5.6
3.7
Workmanship
4.3.2.1 to 4.3.2.21
X
X
X
4.1 Classification of inspections. The following types of inspection shall be conducted for
this item:
a. First article inspection
b. Conformance inspection
4.2 First article inspection. When specified a sample of the M74A1 and its components
and sub assemblies shall be subjected to first article inspection in accordance with Table II.
4.2.1 Inspections to be performed. The first article inspection shall be 100% examination of all
drawing characteristics (listed and unlisted) including workmanship requirements for the parts
and assemblies listed and the tests specified in Table II herein. (See 6.11.1)
4.2.2 Rejection. The first article sample shall be rejected if any of the inspections/tests in
Table II are not acceptable. (See 6.11.2)
